Spring Security - Basic Authentication

. . 6 min read


This guide walks you through the process of building a Spring boot application that uses Spring Security and Spring Data JPA. Applying the new way to configure Spring Security without the WebSecurityConfigurerAdapter

What You Will build

You will build a Spring Boot application with Spring Security basic authentication and Spring Data Jpa for managing the users.

What You Need

  • A favorite text editor or IDE
  • JDK 1.8 or later
  • Gradle 4+ or Maven 3.2+

Setup Project With Spring Initializr

  • Navigate to Spring initializr.

  • Define the project name example: spring-boot-security-basic-auth

  • Choose Project Maven and the language Java.

  • Choose Your Java version ex: 17

  • Click add dependencies and select:

    • Spring Web
    • Spring Security
    • Spring Data JPA
    • H2 Database
    • Lombok
  • Click Generate.

Unzip the Downloaded Zip and open the Project using your favorite text editor or IDE

Start the implementation

Define the User Entity, implement the UserDetails interface and override the implemented methods

@Entity(name = "users")
public class User implements UserDetails {

    @GeneratedValue(strategy = GenerationType.IDENTITY)
    private Long id;

    private String firstName;

    private String lastName;

    @Column(unique = true)
    private String username;

    private String password;

    public Collection<? extends GrantedAuthority> getAuthorities() {
        return Collections.emptyList();

    public String getPassword() {
        return this.password;

    public String getUsername() {
        return this.username;

    public boolean isAccountNonExpired() {
        return true;

    public boolean isAccountNonLocked() {
        return true;

    public boolean isCredentialsNonExpired() {
        return true;

    public boolean isEnabled() {
        return true;


Define the User Repository and the query method findOneByUsername

Lean more about query methods here

public interface UserRepository extends JpaRepository<User, Long> {

    Optional<User> findOneByUsername(String username);

Define the User Details Service implementation that will manage user authentication.

public class CustomUserDetailsService implements UserDetailsService {

    private UserRepository userRepository;

    public CustomUserDetailsService(UserRepository userRepository) {
        this.userRepository = userRepository;

    public UserDetails loadUserByUsername(String username) throws UsernameNotFoundException {
        return userRepository.findOneByUsername(username).orElseThrow(() -> {
            throw new UsernameNotFoundException(username);


Define the Spring Security Configuration, You will notice that we didn't extend the WebSecurityConfigurerAdapter we just define beans at this level

public class SecurityConfiguration {

     * Define the password encoder.
     * @return {@link BCryptPasswordEncoder}
    public PasswordEncoder passwordEncoder() {
        return new BCryptPasswordEncoder();

     * Define the user service to retrieve and authenticate the user.
     * @param userRepository
     * @return {@link UserDetails}
    CustomUserDetailsService customUserDetailsService(UserRepository userRepository) {
        return new CustomUserDetailsService(userRepository);

     * Define the filer chain.
     * @param http
     * @return {@link SecurityFilterChain}
     * @throws Exception
    public SecurityFilterChain filterChain(HttpSecurity http) throws Exception {
                (authz) -> authz.antMatchers("/secured").authenticated().anyRequest().permitAll())
        return http.build();


Define the Rest Controller with some routes

public class AppResource {

    public String any() {
        return "Hello World";

    public String secured(Authentication auth) {
        User user = ((User) auth.getPrincipal());
        return "Hello " + user.getFirstName() + " " + user.getLastName();


Create data.sql under the resources folder to populate our table

                              -- password is '123'
    ('john', 'doe', 'admin', '$2a$12$vl2OJQMtIZutojuJVhaRXuLmkyFV1QgE24HqFPWoYTmPOXa6wOUbi');

When running the application, by default the data.sql will be executed before the entity creation into the database, to prevent that add the following property under the application.properties



Write some test cases to check that the uri /secured is working as expected

  • Test 1 : check with correct credentials
  • Test 2 : check with wrong credentials
@SpringBootTest(webEnvironment = WebEnvironment.RANDOM_PORT)
public class SpringBootSecurityBasicAuthApplicationTests {

	private final String USERNAME = "admin";
	private final String PASSWORD = "123";
	private final String WRONG_PASSWORD = "bvfsdg";

	TestRestTemplate template;

	public void accessPrivateResourceSuccess() throws Exception {
		ResponseEntity<String> response = template.withBasicAuth(USERNAME, PASSWORD)
				.getForEntity("/secured", String.class);

		assertEquals(HttpStatus.OK, response.getStatusCode());

	public void accessPrivateResourceFaildGivingWrongPassword() throws Exception {
		ResponseEntity<String> response = template.withBasicAuth(USERNAME, WRONG_PASSWORD)
				.getForEntity("/secured", String.class);

		assertEquals(HttpStatus.UNAUTHORIZED, response.getStatusCode());


Run The Application

Run the Java application as a SpringBootApplication with your IDE or use the following command line

 ./mvnw spring-boot:run

Now, you can open the URL below on your browser, default port is 8080 you can set it under the application.properties


When you access the secured URI /secured, a prompt shows up pass in the username & password

  • username : admin
  • password : 123


Congratulations 🎉 ! You've created a Spring Security application with basic authentication using Spring Boot & Spring Data JPA


The tutorial can be found here on GitHub 👋
